Energy-saving and demand-controlled comfort module for Swegon’s WISE System

  • Comfort modules for demand-controlled ventilation and Swegon’s WISE system.
  • Energy-efficient operation since the room is ventilated, heated and cooled exactly as called for by the load, neither more nor less.
  • Highest possible comfort with provision for individual control on the product or at room level.
  • Waterborne cooling energy and waterborne or electric heat.
  • Draught-free indoor climate, 4-way air distribution and Swegon’s ADC (Anti Draught Control) provide maximum comfort and flexibility both today and for future needs.
  • Simple installation, commissioning and maintenance.
  • Complete product with all components and accessories installed from the factory.


Primary airflow: Up to 85 l/s

Pressure range: 50 to 150 Pa

Total cooling capacity: Up to 2055 W

Heating capacity:
Water - Up to 2700 W
Electric - Up to 1000 W

Size: 600 and 1200 with adapters for a number of ceiling systems
