EAGLE Single

Circular ceiling diffuser with nozzles for supply air

Adjustable nozzles
100% flexible spread pattern
Can be used for vertical air diffusion
Swirl function
Substantial induction capacity
Can be used with the ALS commissioning box
Available in a galvanized version
Standard colour White RAL 9003
- 5 alternative standard colours
- Other colours upon request

Calculate with your requirements

Circular supply air diffusers with adjustable nozzles for ceiling installation. The air diffuser is well suited for constant as well as variable air flow. Air above or below room temperature can be discharged in a horizontal or vertical spread pattern into the room. The nozzle technique allows the supply of air substantially below room air temperature. It is possible to change the spread pattern after commissioning without altering the air flow, pressure drop or sound level.

AIR FLOW - SOUND PRESSURE ROOM (Lp10A) *)
EAGLE Single Size		25 dB(A)		30 dB(A)		35 dB(A)
EAGLE Single Size		l/s	m3/h	l/s	m3/h	l/s	m3/h
125		34	122	40	144	47	169
160		50	180	58	209	70	252
200		78	281	92	331	108	389
250		105	378	122	439	142	511
315		143	515	168	605	200	720
400		230	828	265	954	310	1116

EAGLE Single Size	ALS Size	25 dB(A)		30 dB(A)		35 dB(A)
EAGLE Single Size	ALS Size	l/s	m3/h	l/s	m3/h	l/s	m3/h
125	100-125	24	86	29	104	36	130
160	125-160	37	133	45	162	55	198
200	160-200	54	194	70	252	85	306
250	200-250	84	302	101	364	124	446
315	250-315	120	432	145	522	170	612
400	315-400	180	648	220	792	265	954
The data for diffuser + ALS commissioning box is specified for 50 Pa total pressure. *) Lp10A = Sound pressure incl. A-filter with 4 dB room attenuation and 10 m² room absorption area.

ALS

Commissioning box for air diffusers

Nordic Swan listed

The product is listed in the database for building products that can be used in Nordic Swan Ecolabelled buildings.
